Model | 4V210-06 | 4V220-06 | 4V230C-06 | 4V230E-06 | 4V230P-06 | 4V210-08 | 4V220-08 | 4V230C-08 | 4V230E-08 | 4V230P-08 |
4A210-06 | 4A220-06 | 4A230C-06 | 4A230E-06 | 4A230P-06 | 4A210-08 | 4A220-08 | 4A230C-08 | 4A230E-08 | 4A230P-08 | |
Position and way NO. | 5/2 way | 5/3Five-way | 5/2 way | 5/3 way | ||||||
Effective area | 14mm2(CV=0.78) | 12mm2(CV=0.67) | 16mm2(CV=0.89) | 12mm2(CV=0.67) | ||||||
Model | 3V210-06 | 3V220-06 | 3A210-06 | 3A220-06 | 3V210-08 | 3V220-08 | 3A210-08 | 3A220-08 | ||
Position and way NO. | 3/2 way | 3/2 way | ||||||||
Effective area | 14mm2(CV=0.78) | 16mm2(CV=0.89) | ||||||||
Port size | Air inlet=Air outlet=Exhaust=G1/8″ | Air inlet=Air outlet=G1/4″ Exhaust=G1/8″ | ||||||||
Fluid | 40 micron fi ltered air | |||||||||
Operation | Inside pilot type | |||||||||
Operating pressure | 0.15~0.8MPa | |||||||||
Max. proof pressure | 1.2MPa | |||||||||
Temperature | 5~50oC | |||||||||
Allowable voltage | ±10% of rated voltage | |||||||||
Power consumption | AAC: 4.5VA DC: 3W | |||||||||
Coil insulation & protection grade | Class F.IP65 | |||||||||
Electrical entry | Lead wire or connector | |||||||||
Highest action frequency | 5 cycle/second | |||||||||
Shortest excitation time | 0.05 second |
型号 AFC2000 BFC2000 BFC3000 BFC4000
接管口径G 1/4” 1/4” 3/8” 1/2”
使用流体 空气
过滤精度 标准:40μm
设定压力范围MPa 0.05~0.85
保证耐压力MPa 1.5
温度范围 -10~60℃
推荐使用油 ISO VG32或同级用油
Construction :diaphragm type
Materials: Aluminum, technopolymer, NBR
Ports :G1/8 - G1/4
Pressure gauge ports: G1/8
Mounting :in-line or panel mounting (in any position)
Operating temperature: 0°C ÷ 50°C
Inlet pressure :0 ÷ 16 bar
Outlet pressure: 0.5 ÷10 bar
Nominal flow: see graphs
Secondary pressure relieving: standard
型号 AFR2000 BFR2000 BFR3000 BFR4000
接管口径G 1/4” 1/4” 3/8” 1/2”
使用流体 空气
过滤精度 标准:40μm
设定压力范围MPa 0.05~0.85
保证耐压力NPa 1.5
温度范围 -10~60℃
推荐使用油 ISOVG32或同级用油
型号 AC2000 AC3000 AC4000 AC5000
接管口径G 1/8”.1/4” 1/4”.3/8” 3/8”.1/2”.3/4” 3/4”.1”
压力表接管口径G 1/8” 1/4”
工作介质 空气
设定压力范围MPa 0.05-0.85
最大处理流量Nl/min 500 2000 4000 5000
温度范围 -10~60℃
过滤精度 标准:5μm
推荐使用油 透平油(ISO VG32)
杯子材质 聚碳酸酯
构造/减压阀 溢流型
附属品(标准装备) 防护罩杯 - ● ● ●
托架 20L 30L 40L 50L
